FRONT FORK / REAR SHOCK SPRING
85/150cc adult specification
SPECIFICATIONS:
- Originally designed a spring that gives the most suitable suspension effect when
going off-road on a mini motocross.
- The optimum spring rate is set for each model with a weight of 65 kg as a guide.
- Achieves stress-free and comfortable sports riding by improving stability and
reducing the feeling of bottoming out on motocross courses.
| Bike | Year | Front | Rear | |||||
| Part# | Spring rate | Comparison with The Stock | Part# | Color | Spring rate | Comparison with The Stock | ||
| CR80R/85R | 96-04 | D35-01-808 | 3.3 N/mm | 11-29% | D35-02-808 | Red | 59.3 N/mm | 16-26% |
| 05-07 | D35-01-818 | 4.1 N/mm | 48% | D35-02-808 | Red | 59.3 N/mm | 21% | |
| CR80RII/85RII | 96-07 | D35-01-808 | 3.3 N/mm | 12-20% | D35-02-808 | Red | 59.3 N/mm | 12-16% |
| CRF150R | 07-21 | D35-01-818 | 4.1 N/mm | 23% | D35-02-808 | Red | 59.3 N/mm | 21% |
| CRF150RII | 07-21 | D35-01-818 | 4.1 N/mm | 16% | D35-02-808 | Red | 59.3 N/mm | 16% |
| YZ80/85 | 97-21 | D35-01-838 | 3.5 N/mm | 25% | D35-02-878 | Red | 60.1 N/mm | 23% |
| YZ80LW/85LW | 97-21 | D35-01-838 | 3.5 N/mm | 21% | D35-02-878 | Blue | 60.1 N/mm | 18% |
| KX80/85 | 01-21 | D35-01-838 | 3.5 N/mm | 23% | D35-02-838 | Blue | 54.8 N/mm | 17% |
| KX80II/85II | 98-21 | D35-01-838 | 3.5 N/mm | 23% | D35-02-838 | Blue | 54.8 N/mm | 17% |
| KX100 | 95-21 | D35-01-838 | 3.5 N/mm | 23% | D35-02-838 | Blue | 54.8 N/mm | 17% |
| RM80/85 | 05-17 | D35-01-808 | 3.3 N/mm | 20% | D35-02-808 | Red | 59.3 N/mm | 32% |
| RM80L/85L | 05-17 | D35-01-808 | 3.3 N/mm | 20% | D35-02-808 | Red | 59.3 N/mm | 26% |
